Manxing Belt Scales are continuous bulk material weighing systems designed for accurate real-time measurement of material flow on belt conveyor systems. They are widely used in cement plants, grain storage facilities, mining operations, biomass projects, power plants, chemical factories, and industrial bulk material handling systems where continuous monitoring and process control are essential.

The system measures the weight of materials moving on a conveyor belt together with belt speed to calculate precise material throughput and total conveyed quantity. Belt scales play a critical role in inventory management, production control, batching operations, and bulk loading systems.

Manxing Belt Scales are suitable for handling powdered, granular, and bulk solid materials such as cement, clinker, fly ash, coal, grain, limestone, biomass pellets, fertilizers, and mineral ores.

Main Applications

Conveyor material flow measurement

Silo discharge monitoring

Bulk loading quantity control

Production line batching systems

Mining material throughput measurement

Grain handling and storage systems

Cement and clinker conveying systems

Continuous process weighing operations

Working Principle

Electronic belt scale is generally composed of scale, weighing sensor, speed sensor and secondary instrument. Weighing of electronic belt scale is to transfer quality of material on conveyor belt and conveyor belt speed into electrical signals through weighing sensor and speed sensor when the material is in the conveying state. Then field amplifier properly processes the two sets of signals and transmits them to main control computer for accumulation, adjustment and control. Finally, the cumulative weighing results are given. This is the automatic and continuous cumulative measurement process of belt scale by using modern control principle.

The belt scale continuously measures the load carried by the conveyor belt through precision load cells installed beneath the weighing idlers. Combined with belt speed sensors, the system calculates the real-time material flow rate and accumulated throughput.

The weighing data can be transmitted to PLC or DCS systems for automated process control, inventory tracking, and production optimization.

Traditional bulk material conveying systems often face operational issues such as:

Inaccurate material flow measurement

Material overfeeding or underfeeding

Production instability caused by inconsistent flow rates

Inventory calculation errors

Conveyor vibration affecting weighing precision

Dust accumulation damaging sensors and components

Difficult calibration and high maintenance costs

These issues can lead to material waste, reduced production efficiency, unstable batching performance, and inaccurate operational data.

Manxing Advantages

Manxing Belt Scales are designed for stable and high-accuracy industrial operation under demanding bulk material handling conditions.

Our advantages include:

High weighing accuracy and stable measurement performance

Durable heavy-duty structural design

Reliable operation in dusty industrial environments

Optimized anti-vibration weighing structure

Suitable for large-capacity conveyor systems

Easy calibration and low maintenance requirements

Real-time monitoring and intelligent automation integration

Compatible with PLC, SCADA, and DCS control systems

Manxing customizes the weighing structure, conveyor integration, and automation configuration according to material characteristics, conveyor capacity, belt width, and project operating conditions.

Typical Silo Matching Solutions

Cement Plant Solution

Cement clinker discharged from storage silos is transported through belt conveyors equipped with belt scales to accurately monitor material flow into grinding systems and production lines.

Mining Industry Solution

Mineral ores and limestone reclaimed from storage silos are transferred through heavy-duty belt conveyors with belt scales for continuous throughput monitoring before entering crushing or processing systems.

Biomass Energy Solution

Biomass pellets discharged from biomass silos are conveyed through belt conveyor systems equipped with belt scales to ensure stable fuel feeding rates for biomass boiler systems.

Integration with Manxing Silo Systems

Manxing Belt Scales can be integrated with:

Flat Bottom Silos

Hopper Bottom Silos

Belt Conveyor Systems

Chain Conveyor Systems

Bulk Loading Systems

Batching & Dosing Systems

Truck and Ship Loading Systems

PLC/DCS Automation Systems

This enables Manxing to provide complete bulk material storage, conveying, weighing, and process automation solutions for modern industrial facilities.
